MODEL

SX32556R434

Driver position

Left Hand

Driving type

6*4

Wheelbase/(mm)

4375+1400

Max. Speed/(km/h)

75 km/h

Engine

Brand

WEICHAI

Model

WP10.340E22

Emission Standard

EURO II

Rated output power（PS）

340

Displacement(L)

9.762L

Transmission

Brand

FAST

Model

 10JSD180+QH50

Front axle

Brand

HANDE

Model

MAN 9.5T

Rear axle

Brand

HANDE

Model

16T MAN double reduction driving axle 5.92

Clutch

￠430 diaphragm clutch

Steering

ZF technology

Frame

850×300（8+7）

Suspension

multiple leaf springs front and rear/four main spring + four bolts

Fuel tank

400L aluminium alloy

Wheels and tires

12.00R 20 (10+1)

Brakes

Running brake:Dual circuit compressed air brake

Parking brake:Air discharging with spring control

Auxiliary brake:Engine exhaust brake

 Cabin

X3000 medium and long flat top cab, hydraulic main seat, four-point hydraulic suspension cab, electronic control automatic constant temperature air conditioning, electric shaking window machine, ordinary rearview mirror, manual flip, telescopic shaft control, ordinary air filter, metal bumper, daytime running lights, more chain type board pedals, rim decoration cover, reversing buzzer, water tank protection grid, 165Ah maintenance-free battery, plus army With tow hook + eight - shaped tail beam, full trailer electrical road interface, SHACMAN logo, full English logo

Upbody

Large box size :6300*2450*(1500+500)/bottom plate thickness :4/ side plate thickness :2/ Lifting form: three sides over/cylinder brand: domestic/large box color: glacier white /
